MOC wide-angle image M09-03067

context image for 3066


MOC wide-angle image M09-03067
MOC wide-angle image M09-03067
View full-size image, processed, in sinusoidal projection using 252.04°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 252.04°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M09-03067

Acquisition parameters
     Image ID (picno): M09-03067
     Image start time: 1999-11-12T20:07:09.20 SCET
         Image  width:    480      pixels
         Image height:    720      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.05
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-PRED-X-5
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    252.04°W
Latitude  of image center:     20.87°S
       Scaled pixel width:    236.44   meters
      Scaled image  width:    114.57   km
      Scaled image height:    178.87   km
     Solar longitude (Ls):    242.97°
    Local True Solar Time:     14.35   decimal hours
           Emission angle:      3.47°
          Incidence angle:     32.98°
              Phase angle:     29.56°
            North azimuth:     93.37°
              Sun azimuth:    354.28°
      Spacecraft altitude:    374.98   km
           Slant distance:    375.60   km

Policy regarding use of processed images

Release date: 16 October 2000
