MOC wide-angle image M09-03059

context image for 3058


MOC wide-angle image M09-03059
MOC wide-angle image M09-03059
View full-size image, processed, in sinusoidal projection using 226.24°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 226.24°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M09-03059

Acquisition parameters
     Image ID (picno): M09-03059
     Image start time: 1999-11-12T18:16:28.83 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.02
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-PRED-X-5
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    226.24°W
Latitude  of image center:      0.30°N
       Scaled pixel width:    242.78   meters
      Scaled image  width:    117.55   km
      Scaled image height:    118.80   km
     Solar longitude (Ls):    242.92°
    Local True Solar Time:     14.28   decimal hours
           Emission angle:      3.47°
          Incidence angle:     40.36°
              Phase angle:     37.58°
            North azimuth:     92.95°
              Sun azimuth:    326.70°
      Spacecraft altitude:    384.42   km
           Slant distance:    385.05   km

Policy regarding use of processed images

Release date: 16 October 2000
