MOC wide-angle image M09-02578

context image for 2577


MOC wide-angle image M09-02578
MOC wide-angle image M09-02578
View full-size image, processed, in sinusoidal projection using 259.11°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 259.11°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M09-02578

Acquisition parameters
     Image ID (picno): M09-02578
     Image start time: 1999-11-10T19:12:38.48 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.02
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    259.11°W
Latitude  of image center:      0.55°S
       Scaled pixel width:    241.95   meters
      Scaled image  width:    117.15   km
      Scaled image height:    118.88   km
     Solar longitude (Ls):    241.68°
    Local True Solar Time:     14.30   decimal hours
           Emission angle:      3.48°
          Incidence angle:     40.02°
              Phase angle:     37.04°
            North azimuth:     93.02°
              Sun azimuth:    328.17°
      Spacecraft altitude:    383.10   km
           Slant distance:    383.74   km

Policy regarding use of processed images

Release date: 16 October 2000
