MOC wide-angle image M09-01275

context image for 1274


MOC wide-angle image M09-01275
MOC wide-angle image M09-01275
View full-size image, processed, in sinusoidal projection using 225.26°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 225.26°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M09-01275

Acquisition parameters
     Image ID (picno): M09-01275
     Image start time: 1999-11-05T13:38:34.65 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.04
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    225.26°W
Latitude  of image center:     14.67°S
       Scaled pixel width:    238.21   meters
      Scaled image  width:    115.38   km
      Scaled image height:    119.12   km
     Solar longitude (Ls):    238.37°
    Local True Solar Time:     14.40   decimal hours
           Emission angle:      3.46°
          Incidence angle:     34.93°
              Phase angle:     31.62°
            North azimuth:     93.13°
              Sun azimuth:    346.90°
      Spacecraft altitude:    377.49   km
           Slant distance:    378.11   km

Policy regarding use of processed images

Release date: 16 October 2000
