MOC wide-angle image M09-01019

context image for 1018


MOC wide-angle image M09-01019
MOC wide-angle image M09-01019
View full-size image, processed, in sinusoidal projection using 240.51°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 240.51°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M09-01019

Acquisition parameters
     Image ID (picno): M09-01019
     Image start time: 1999-11-04T14:03:54.66 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.05
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    240.51°W
Latitude  of image center:     23.65°S
       Scaled pixel width:    236.04   meters
      Scaled image  width:    114.40   km
      Scaled image height:    119.12   km
     Solar longitude (Ls):    237.75°
    Local True Solar Time:     14.44   decimal hours
           Emission angle:      3.46°
          Incidence angle:     34.06°
              Phase angle:     30.60°
            North azimuth:     93.42°
              Sun azimuth:      0.33°
      Spacecraft altitude:    374.52   km
           Slant distance:    375.14   km

Policy regarding use of processed images

Release date: 16 October 2000
