MOC wide-angle image M09-00739

context image for 738


MOC wide-angle image M09-00739
MOC wide-angle image M09-00739
View full-size image, processed, in sinusoidal projection using 258.61°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 258.61°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M09-00739

Acquisition parameters
     Image ID (picno): M09-00739
     Image start time: 1999-11-03T14:35:55.30 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.04
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    258.61°W
Latitude  of image center:     11.82°S
       Scaled pixel width:    238.57   meters
      Scaled image  width:    115.54   km
      Scaled image height:    119.14   km
     Solar longitude (Ls):    237.13°
    Local True Solar Time:     14.41   decimal hours
           Emission angle:      3.46°
          Incidence angle:     35.89°
              Phase angle:     32.65°
            North azimuth:     93.15°
              Sun azimuth:    343.65°
      Spacecraft altitude:    377.96   km
           Slant distance:    378.58   km

Policy regarding use of processed images

Release date: 16 October 2000
