MOC wide-angle image M09-00073

context image for 72


MOC wide-angle image M09-00073
MOC wide-angle image M09-00073
View full-size image, processed, in sinusoidal projection using 232.87°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 232.87°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M09-00073

Acquisition parameters
     Image ID (picno): M09-00073
     Image start time: 1999-11-01T11:33:30.32 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.05
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    232.87°W
Latitude  of image center:     22.83°S
       Scaled pixel width:    236.10   meters
      Scaled image  width:    114.42   km
      Scaled image height:    119.15   km
     Solar longitude (Ls):    235.79°
    Local True Solar Time:     14.47   decimal hours
           Emission angle:      3.46°
          Incidence angle:     34.52°
              Phase angle:     31.07°
            North azimuth:     93.34°
              Sun azimuth:    359.80°
      Spacecraft altitude:    374.57   km
           Slant distance:    375.18   km

Policy regarding use of processed images

Release date: 16 October 2000
