MOC wide-angle image M08-07942

context image for 7941


MOC wide-angle image M08-07942
MOC wide-angle image M08-07942
View full-size image, processed, in sinusoidal projection using 250.23°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 250.23°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M08-07942

Acquisition parameters
     Image ID (picno): M08-07942
     Image start time: 1999-10-31T12:03:45.83 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.05
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    250.23°W
Latitude  of image center:     16.46°S
       Scaled pixel width:    237.44   meters
      Scaled image  width:    115.02   km
      Scaled image height:    119.17   km
     Solar longitude (Ls):    235.17°
    Local True Solar Time:     14.45   decimal hours
           Emission angle:      3.45°
          Incidence angle:     35.19°
              Phase angle:     31.83°
            North azimuth:     93.23°
              Sun azimuth:    350.92°
      Spacecraft altitude:    376.36   km
           Slant distance:    376.98   km

Policy regarding use of processed images

Release date: 16 October 2000
