MOC wide-angle image M08-07593

context image for 7592


MOC wide-angle image M08-07593
MOC wide-angle image M08-07593
View full-size image, processed, in sinusoidal projection using 266.73°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 266.73°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M08-07593

Acquisition parameters
     Image ID (picno): M08-07593
     Image start time: 1999-10-30T12:32:01.84 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.05
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    266.73°W
Latitude  of image center:     16.30°S
       Scaled pixel width:    237.34   meters
      Scaled image  width:    114.97   km
      Scaled image height:    119.20   km
     Solar longitude (Ls):    234.55°
    Local True Solar Time:     14.46   decimal hours
           Emission angle:      3.44°
          Incidence angle:     35.34°
              Phase angle:     31.99°
            North azimuth:     93.24°
              Sun azimuth:    351.00°
      Spacecraft altitude:    376.20   km
           Slant distance:    376.82   km

Policy regarding use of processed images

Release date: 16 October 2000
