MOC wide-angle image M08-06397

context image for 6396


MOC wide-angle image M08-06397
MOC wide-angle image M08-06397
View full-size image, processed, in sinusoidal projection using 248.45°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 248.45°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M08-06397

Acquisition parameters
     Image ID (picno): M08-06397
     Image start time: 1999-10-26T08:35:50.13 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.03
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-PRED-X-5
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    248.45°W
Latitude  of image center:      4.11°S
       Scaled pixel width:    240.89   meters
      Scaled image  width:    116.64   km
      Scaled image height:    118.97   km
     Solar longitude (Ls):    231.93°
    Local True Solar Time:     14.45   decimal hours
           Emission angle:      3.46°
          Incidence angle:     39.15°
              Phase angle:     36.07°
            North azimuth:     93.00°
              Sun azimuth:    336.65°
      Spacecraft altitude:    381.45   km
           Slant distance:    382.08   km

Policy regarding use of processed images

Release date: 16 October 2000
