MOC wide-angle image M08-05909

context image for 5908


MOC wide-angle image M08-05909
MOC wide-angle image M08-05909
View full-size image, processed, in sinusoidal projection using 251.36°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 251.36°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M08-05909

Acquisition parameters
     Image ID (picno): M08-05909
     Image start time: 1999-10-24T07:31:03.16 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.05
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-PRED-X-5
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    251.36°W
Latitude  of image center:     15.15°S
       Scaled pixel width:    237.69   meters
      Scaled image  width:    115.13   km
      Scaled image height:    119.17   km
     Solar longitude (Ls):    230.65°
    Local True Solar Time:     14.50   decimal hours
           Emission angle:      3.44°
          Incidence angle:     36.21°
              Phase angle:     32.85°
            North azimuth:     93.16°
              Sun azimuth:    351.19°
      Spacecraft altitude:    376.70   km
           Slant distance:    377.31   km

Policy regarding use of processed images

Release date: 16 October 2000
