MOC wide-angle image M08-04234

context image for 4233


MOC wide-angle image M08-04234
MOC wide-angle image M08-04234
View full-size image, processed, in sinusoidal projection using 265.15°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 265.15°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M08-04234

Acquisition parameters
     Image ID (picno): M08-04234
     Image start time: 1999-10-18T04:29:03.22 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.04
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-PRED-X-5
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    265.15°W
Latitude  of image center:      9.88°S
       Scaled pixel width:    238.88   meters
      Scaled image  width:    115.68   km
      Scaled image height:    119.14   km
     Solar longitude (Ls):    226.81°
    Local True Solar Time:     14.53   decimal hours
           Emission angle:      3.44°
          Incidence angle:     37.81°
              Phase angle:     34.54°
            North azimuth:     93.12°
              Sun azimuth:    346.30°
      Spacecraft altitude:    378.41   km
           Slant distance:    379.02   km

Policy regarding use of processed images

Release date: 16 October 2000
