MOC wide-angle image M08-03898

context image for 3897


MOC wide-angle image M08-03898
MOC wide-angle image M08-03898
View full-size image, processed, in sinusoidal projection using 254.18°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 254.18°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M08-03898

Acquisition parameters
     Image ID (picno): M08-03898
     Image start time: 1999-10-17T03:02:28.98 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.03
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-PRED-X-5
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    254.18°W
Latitude  of image center:      0.97°S
       Scaled pixel width:    241.81   meters
      Scaled image  width:    117.08   km
      Scaled image height:    118.91   km
     Solar longitude (Ls):    226.14°
    Local True Solar Time:     14.51   decimal hours
           Emission angle:      3.45°
          Incidence angle:     40.75°
              Phase angle:     37.70°
            North azimuth:     93.00°
              Sun azimuth:    336.21°
      Spacecraft altitude:    382.90   km
           Slant distance:    383.52   km

Policy regarding use of processed images

Release date: 16 October 2000
