MOC wide-angle image M08-03875

context image for 3874


MOC wide-angle image M08-03875
MOC wide-angle image M08-03875
View full-size image, processed, in sinusoidal projection using 224.13°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 224.13°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M08-03875

Acquisition parameters
     Image ID (picno): M08-03875
     Image start time: 1999-10-17T01:01:15.48 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.04
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    224.13°W
Latitude  of image center:     12.00°S
       Scaled pixel width:    238.79   meters
      Scaled image  width:    115.65   km
      Scaled image height:    119.11   km
     Solar longitude (Ls):    226.09°
    Local True Solar Time:     14.54   decimal hours
           Emission angle:      3.45°
          Incidence angle:     37.42°
              Phase angle:     34.07°
            North azimuth:     93.08°
              Sun azimuth:    349.30°
      Spacecraft altitude:    378.32   km
           Slant distance:    378.94   km

Policy regarding use of processed images

Release date: 16 October 2000
