MOC wide-angle image M08-03525

context image for 3524


MOC wide-angle image M08-03525
MOC wide-angle image M08-03525
View full-size image, processed, in sinusoidal projection using 268.20°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 268.20°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M08-03525

Acquisition parameters
     Image ID (picno): M08-03525
     Image start time: 1999-10-16T03:24:40.74 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.05
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    268.20°W
Latitude  of image center:     19.59°S
       Scaled pixel width:    236.45   meters
      Scaled image  width:    114.57   km
      Scaled image height:    119.21   km
     Solar longitude (Ls):    225.53°
    Local True Solar Time:     14.58   decimal hours
           Emission angle:      3.43°
          Incidence angle:     36.80°
              Phase angle:     33.39°
            North azimuth:     93.34°
              Sun azimuth:    359.75°
      Spacecraft altitude:    374.97   km
           Slant distance:    375.58   km

Policy regarding use of processed images

Release date: 16 October 2000
