MOC wide-angle image M08-03523

context image for 3522


MOC wide-angle image M08-03523
MOC wide-angle image M08-03523
View full-size image, processed, in sinusoidal projection using 267.32°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 267.32°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M08-03523

Acquisition parameters
     Image ID (picno): M08-03523
     Image start time: 1999-10-16T03:22:40.74 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.06
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    267.32°W
Latitude  of image center:     25.79°S
       Scaled pixel width:    235.23   meters
      Scaled image  width:    114.03   km
      Scaled image height:    119.14   km
     Solar longitude (Ls):    225.53°
    Local True Solar Time:     14.61   decimal hours
           Emission angle:      3.42°
          Incidence angle:     37.22°
              Phase angle:     33.80°
            North azimuth:     93.52°
              Sun azimuth:      8.02°
      Spacecraft altitude:    373.40   km
           Slant distance:    374.00   km

Policy regarding use of processed images

Release date: 16 October 2000
