MOC wide-angle image M08-03484

context image for 3483


MOC wide-angle image M08-03484
MOC wide-angle image M08-03484
View full-size image, processed, in sinusoidal projection using 240.95°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 240.95°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M08-03484

Acquisition parameters
     Image ID (picno): M08-03484
     Image start time: 1999-10-16T01:30:18.87 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.04
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    240.95°W
Latitude  of image center:      9.45°S
       Scaled pixel width:    239.32   meters
      Scaled image  width:    115.89   km
      Scaled image height:    119.10   km
     Solar longitude (Ls):    225.48°
    Local True Solar Time:     14.54   decimal hours
           Emission angle:      3.47°
          Incidence angle:     38.05°
              Phase angle:     34.74°
            North azimuth:     93.08°
              Sun azimuth:    346.44°
      Spacecraft altitude:    379.06   km
           Slant distance:    379.69   km

Policy regarding use of processed images

Release date: 16 October 2000
