MOC wide-angle image M08-03243

context image for 3242


MOC wide-angle image M08-03243
MOC wide-angle image M08-03243
View full-size image, processed, in sinusoidal projection using 255.88°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 255.88°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M08-03243

Acquisition parameters
     Image ID (picno): M08-03243
     Image start time: 1999-10-15T01:54:47.50 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.05
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    255.88°W
Latitude  of image center:     20.97°S
       Scaled pixel width:    236.23   meters
      Scaled image  width:    114.47   km
      Scaled image height:    119.18   km
     Solar longitude (Ls):    224.87°
    Local True Solar Time:     14.59   decimal hours
           Emission angle:      3.42°
          Incidence angle:     36.95°
              Phase angle:     33.53°
            North azimuth:     93.34°
              Sun azimuth:      1.88°
      Spacecraft altitude:    374.69   km
           Slant distance:    375.29   km

Policy regarding use of processed images

Release date: 16 October 2000
