MOC wide-angle image M08-02755

context image for 2754


MOC wide-angle image M08-02755
MOC wide-angle image M08-02755
View full-size image, processed, in sinusoidal projection using 259.82°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 259.82°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M08-02755

Acquisition parameters
     Image ID (picno): M08-02755
     Image start time: 1999-10-13T00:52:36.27 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.05
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-PRED-X-5
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    259.82°W
Latitude  of image center:     23.90°S
       Scaled pixel width:    235.54   meters
      Scaled image  width:    114.16   km
      Scaled image height:    119.17   km
     Solar longitude (Ls):    223.59°
    Local True Solar Time:     14.62   decimal hours
           Emission angle:      3.43°
          Incidence angle:     37.44°
              Phase angle:     34.01°
            North azimuth:     93.41°
              Sun azimuth:      6.32°
      Spacecraft altitude:    373.76   km
           Slant distance:    374.36   km

Policy regarding use of processed images

Release date: 16 October 2000
