MOC wide-angle image M08-02564

context image for 2563


MOC wide-angle image M08-02564
MOC wide-angle image M08-02564
View full-size image, processed, in sinusoidal projection using 250.79°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 250.79°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M08-02564

Acquisition parameters
     Image ID (picno): M08-02564
     Image start time: 1999-10-11T23:30:35.78 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.03
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    250.79°W
Latitude  of image center:      0.82°S
       Scaled pixel width:    241.84   meters
      Scaled image  width:    117.09   km
      Scaled image height:    118.91   km
     Solar longitude (Ls):    222.94°
    Local True Solar Time:     14.54   decimal hours
           Emission angle:      3.46°
          Incidence angle:     40.91°
              Phase angle:     37.79°
            North azimuth:     93.00°
              Sun azimuth:    337.77°
      Spacecraft altitude:    382.93   km
           Slant distance:    383.56   km

Policy regarding use of processed images

Release date: 16 October 2000
