MOC wide-angle image M08-02151

context image for 2150


MOC wide-angle image M08-02151
MOC wide-angle image M08-02151
View full-size image, processed, in sinusoidal projection using 226.11°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 226.11°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M08-02151

Acquisition parameters
     Image ID (picno): M08-02151
     Image start time: 1999-10-09T20:30:39.18 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.03
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    226.11°W
Latitude  of image center:      4.04°S
       Scaled pixel width:    241.16   meters
      Scaled image  width:    116.77   km
      Scaled image height:    118.95   km
     Solar longitude (Ls):    221.61°
    Local True Solar Time:     14.56   decimal hours
           Emission angle:      3.46°
          Incidence angle:     39.84°
              Phase angle:     36.61°
            North azimuth:     92.96°
              Sun azimuth:    342.00°
      Spacecraft altitude:    381.88   km
           Slant distance:    382.50   km

Policy regarding use of processed images

Release date: 16 October 2000
