MOC wide-angle image M08-01997

context image for 1996


MOC wide-angle image M08-01997
MOC wide-angle image M08-01997
View full-size image, processed, in sinusoidal projection using 242.73°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 242.73°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M08-01997

Acquisition parameters
     Image ID (picno): M08-01997
     Image start time: 1999-10-08T20:59:11.56 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.03
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    242.73°W
Latitude  of image center:      3.06°S
       Scaled pixel width:    241.21   meters
      Scaled image  width:    116.79   km
      Scaled image height:    118.96   km
     Solar longitude (Ls):    221.01°
    Local True Solar Time:     14.56   decimal hours
           Emission angle:      3.47°
          Incidence angle:     40.19°
              Phase angle:     36.98°
            North azimuth:     93.00°
              Sun azimuth:    341.27°
      Spacecraft altitude:    381.93   km
           Slant distance:    382.57   km

Policy regarding use of processed images

Release date: 16 October 2000
