MOC wide-angle image M08-01995

context image for 1994


MOC wide-angle image M08-01995
MOC wide-angle image M08-01995
View full-size image, processed, in sinusoidal projection using 239.12°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 239.12°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M08-01995

Acquisition parameters
     Image ID (picno): M08-01995
     Image start time: 1999-10-08T20:50:38.94 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.06
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    239.12°W
Latitude  of image center:     29.56°S
       Scaled pixel width:    234.80   meters
      Scaled image  width:    113.86   km
      Scaled image height:    119.06   km
     Solar longitude (Ls):    221.00°
    Local True Solar Time:     14.67   decimal hours
           Emission angle:      3.45°
          Incidence angle:     39.10°
              Phase angle:     35.72°
            North azimuth:     93.59°
              Sun azimuth:     14.47°
      Spacecraft altitude:    372.97   km
           Slant distance:    373.58   km

Policy regarding use of processed images

Release date: 16 October 2000
