MOC wide-angle image M08-01271

context image for 1270


MOC wide-angle image M08-01271
MOC wide-angle image M08-01271
View full-size image, processed, in sinusoidal projection using 235.46°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 235.46°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M08-01271

Acquisition parameters
     Image ID (picno): M08-01271
     Image start time: 1999-10-05T18:29:36.85 SCET
         Image  width:    480      pixels
         Image height:    688      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.02
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    235.46°W
Latitude  of image center:      0.86°N
       Scaled pixel width:    242.59   meters
      Scaled image  width:    117.46   km
      Scaled image height:    169.92   km
     Solar longitude (Ls):    219.08°
    Local True Solar Time:     14.57   decimal hours
           Emission angle:      3.47°
          Incidence angle:     41.60°
              Phase angle:     38.49°
            North azimuth:     92.92°
              Sun azimuth:    338.01°
      Spacecraft altitude:    384.11   km
           Slant distance:    384.74   km

Policy regarding use of processed images

Release date: 16 October 2000
