MOC wide-angle image M08-01058

context image for 1057


MOC wide-angle image M08-01058
MOC wide-angle image M08-01058
View full-size image, processed, in sinusoidal projection using 251.42°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 251.42°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M08-01058

Acquisition parameters
     Image ID (picno): M08-01058
     Image start time: 1999-10-04T18:56:37.61 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.03
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    251.42°W
Latitude  of image center:      3.21°S
       Scaled pixel width:    241.01   meters
      Scaled image  width:    116.70   km
      Scaled image height:    118.97   km
     Solar longitude (Ls):    218.48°
    Local True Solar Time:     14.59   decimal hours
           Emission angle:      3.47°
          Incidence angle:     40.25°
              Phase angle:     37.00°
            North azimuth:     93.03°
              Sun azimuth:    342.88°
      Spacecraft altitude:    381.64   km
           Slant distance:    382.27   km

Policy regarding use of processed images

Release date: 16 October 2000
