MOC wide-angle image M08-00778

context image for 777


MOC wide-angle image M08-00778
MOC wide-angle image M08-00778
View full-size image, processed, in sinusoidal projection using 266.72°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 266.72°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M08-00778

Acquisition parameters
     Image ID (picno): M08-00778
     Image start time: 1999-10-03T19:21:48.12 SCET
         Image  width:    480      pixels
         Image height:    640      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.04
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    266.72°W
Latitude  of image center:     12.27°S
       Scaled pixel width:    238.18   meters
      Scaled image  width:    115.35   km
      Scaled image height:    158.98   km
     Solar longitude (Ls):    217.87°
    Local True Solar Time:     14.62   decimal hours
           Emission angle:      3.43°
          Incidence angle:     38.47°
              Phase angle:     35.09°
            North azimuth:     93.16°
              Sun azimuth:    354.18°
      Spacecraft altitude:    377.38   km
           Slant distance:    377.99   km

Policy regarding use of processed images

Release date: 16 October 2000
