MOC wide-angle image M08-00417

context image for 416


MOC wide-angle image M08-00417
MOC wide-angle image M08-00417
View full-size image, processed, in sinusoidal projection using 253.15°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 253.15°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M08-00417

Acquisition parameters
     Image ID (picno): M08-00417
     Image start time: 1999-10-02T17:49:03.13 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.05
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    253.15°W
Latitude  of image center:     22.82°S
       Scaled pixel width:    235.87   meters
      Scaled image  width:    114.31   km
      Scaled image height:    119.18   km
     Solar longitude (Ls):    217.21°
    Local True Solar Time:     14.67   decimal hours
           Emission angle:      3.42°
          Incidence angle:     38.75°
              Phase angle:     35.34°
            North azimuth:     93.34°
              Sun azimuth:      7.81°
      Spacecraft altitude:    374.24   km
           Slant distance:    374.84   km

Policy regarding use of processed images

Release date: 16 October 2000
