MOC wide-angle image M07-05998

context image for 5997


MOC wide-angle image M07-05998
MOC wide-angle image M07-05998
View full-size image, processed, in sinusoidal projection using 257.78°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 257.78°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M07-05998

Acquisition parameters
     Image ID (picno): M07-05998
     Image start time: 1999-09-30T16:48:25.02 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.05
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    257.78°W
Latitude  of image center:     20.85°S
       Scaled pixel width:    236.21   meters
      Scaled image  width:    114.46   km
      Scaled image height:    119.20   km
     Solar longitude (Ls):    215.96°
    Local True Solar Time:     14.67   decimal hours
           Emission angle:      3.43°
          Incidence angle:     38.78°
              Phase angle:     35.36°
            North azimuth:     93.32°
              Sun azimuth:      6.01°
      Spacecraft altitude:    374.65   km
           Slant distance:    375.26   km

Policy regarding use of processed images

Release date: 16 October 2000
