MOC wide-angle image M07-05960

context image for 5959


MOC wide-angle image M07-05960
MOC wide-angle image M07-05960
View full-size image, processed, in sinusoidal projection using 230.04°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 230.04°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M07-05960

Acquisition parameters
     Image ID (picno): M07-05960
     Image start time: 1999-09-30T14:52:49.65 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.04
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    230.04°W
Latitude  of image center:     14.44°S
       Scaled pixel width:    237.98   meters
      Scaled image  width:    115.27   km
      Scaled image height:    119.17   km
     Solar longitude (Ls):    215.91°
    Local True Solar Time:     14.65   decimal hours
           Emission angle:      3.47°
          Incidence angle:     38.56°
              Phase angle:     35.11°
            North azimuth:     93.12°
              Sun azimuth:    357.93°
      Spacecraft altitude:    377.11   km
           Slant distance:    377.74   km

Policy regarding use of processed images

Release date: 16 October 2000
