MOC wide-angle image M07-05254

context image for 5253


MOC wide-angle image M07-05254
MOC wide-angle image M07-05254
View full-size image, processed, in sinusoidal projection using 251.97°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 251.97°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M07-05254

Acquisition parameters
     Image ID (picno): M07-05254
     Image start time: 1999-09-27T14:22:24.93 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.03
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    251.97°W
Latitude  of image center:      6.20°S
       Scaled pixel width:    240.15   meters
      Scaled image  width:    116.29   km
      Scaled image height:    119.05   km
     Solar longitude (Ls):    214.05°
    Local True Solar Time:     14.63   decimal hours
           Emission angle:      3.42°
          Incidence angle:     39.72°
              Phase angle:     36.41°
            North azimuth:     93.06°
              Sun azimuth:    348.90°
      Spacecraft altitude:    380.35   km
           Slant distance:    380.96   km

Policy regarding use of processed images

Release date: 16 October 2000
