MOC wide-angle image M07-04089

context image for 4088


MOC wide-angle image M07-04089
MOC wide-angle image M07-04089
View full-size image, processed, in sinusoidal projection using 261.60°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 261.60°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M07-04089

Acquisition parameters
     Image ID (picno): M07-04089
     Image start time: 1999-09-21T11:10:39.12 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.06
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-PRED-X-5
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    261.60°W
Latitude  of image center:     30.82°S
       Scaled pixel width:    234.48   meters
      Scaled image  width:    113.72   km
      Scaled image height:    119.06   km
     Solar longitude (Ls):    210.30°
    Local True Solar Time:     14.76   decimal hours
           Emission angle:      3.41°
          Incidence angle:     42.42°
              Phase angle:     39.15°
            North azimuth:     93.69°
              Sun azimuth:     20.06°
      Spacecraft altitude:    372.58   km
           Slant distance:    373.17   km

Policy regarding use of processed images

Release date: 16 October 2000
