MOC wide-angle image M07-03653

context image for 3652


MOC wide-angle image M07-03653
MOC wide-angle image M07-03653
View full-size image, processed, in sinusoidal projection using 240.30°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 240.30°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M07-03653

Acquisition parameters
     Image ID (picno): M07-03653
     Image start time: 1999-09-19T08:18:33.14 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.04
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-PRED-X-5
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    240.30°W
Latitude  of image center:      9.67°S
       Scaled pixel width:    239.37   meters
      Scaled image  width:    115.92   km
      Scaled image height:    119.07   km
     Solar longitude (Ls):    209.01°
    Local True Solar Time:     14.68   decimal hours
           Emission angle:      3.44°
          Incidence angle:     39.63°
              Phase angle:     36.21°
            North azimuth:     93.09°
              Sun azimuth:    356.04°
      Spacecraft altitude:    379.17   km
           Slant distance:    379.79   km

Policy regarding use of processed images

Release date: 16 October 2000
