MOC wide-angle image M07-01426

context image for 1425


MOC wide-angle image M07-01426
MOC wide-angle image M07-01426
View full-size image, processed, in sinusoidal projection using 250.67°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 250.67°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M07-01426

Acquisition parameters
     Image ID (picno): M07-01426
     Image start time: 1999-09-08T01:44:32.88 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.03
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-PRED-X-5
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    250.67°W
Latitude  of image center:      3.70°S
       Scaled pixel width:    241.09   meters
      Scaled image  width:    116.73   km
      Scaled image height:    118.98   km
     Solar longitude (Ls):    202.22°
    Local True Solar Time:     14.69   decimal hours
           Emission angle:      3.46°
          Incidence angle:     40.58°
              Phase angle:     37.17°
            North azimuth:     93.08°
              Sun azimuth:    353.15°
      Spacecraft altitude:    381.76   km
           Slant distance:    382.39   km

Policy regarding use of processed images

Release date: 16 October 2000
