MOC wide-angle image M07-01109

context image for 1108


MOC wide-angle image M07-01109
MOC wide-angle image M07-01109
View full-size image, processed, in sinusoidal projection using 252.72°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 252.72°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M07-01109

Acquisition parameters
     Image ID (picno): M07-01109
     Image start time: 1999-09-06T00:37:42.02 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.05
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-PRED-X-5
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    252.72°W
Latitude  of image center:     20.94°S
       Scaled pixel width:    236.43   meters
      Scaled image  width:    114.56   km
      Scaled image height:    119.15   km
     Solar longitude (Ls):    200.99°
    Local True Solar Time:     14.75   decimal hours
           Emission angle:      3.44°
          Incidence angle:     41.76°
              Phase angle:     38.38°
            North azimuth:     93.40°
              Sun azimuth:     13.96°
      Spacecraft altitude:    375.00   km
           Slant distance:    375.61   km

Policy regarding use of processed images

Release date: 16 October 2000
