MOC wide-angle image M07-01085

context image for 1084


MOC wide-angle image M07-01085
MOC wide-angle image M07-01085
View full-size image, processed, in sinusoidal projection using 224.04°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 224.04°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M07-01085

Acquisition parameters
     Image ID (picno): M07-01085
     Image start time: 1999-09-05T22:39:51.40 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.05
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    224.04°W
Latitude  of image center:     21.50°S
       Scaled pixel width:    236.54   meters
      Scaled image  width:    114.62   km
      Scaled image height:    119.12   km
     Solar longitude (Ls):    200.95°
    Local True Solar Time:     14.76   decimal hours
           Emission angle:      3.44°
          Incidence angle:     41.88°
              Phase angle:     38.51°
            North azimuth:     93.32°
              Sun azimuth:     14.52°
      Spacecraft altitude:    375.20   km
           Slant distance:    375.82   km

Policy regarding use of processed images

Release date: 16 October 2000
