MOC wide-angle image M07-00682

context image for 681


MOC wide-angle image M07-00682
MOC wide-angle image M07-00682
View full-size image, processed, in sinusoidal projection using 259.72°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 259.72°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M07-00682

Acquisition parameters
     Image ID (picno): M07-00682
     Image start time: 1999-09-03T23:42:50.67 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.03
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    259.72°W
Latitude  of image center:      0.94°S
       Scaled pixel width:    241.86   meters
      Scaled image  width:    117.10   km
      Scaled image height:    118.91   km
     Solar longitude (Ls):    199.78°
    Local True Solar Time:     14.69   decimal hours
           Emission angle:      3.48°
          Incidence angle:     40.97°
              Phase angle:     37.56°
            North azimuth:     93.08°
              Sun azimuth:    351.49°
      Spacecraft altitude:    382.95   km
           Slant distance:    383.59   km

Policy regarding use of processed images

Release date: 16 October 2000
