MOC wide-angle image M07-00468

context image for 467


MOC wide-angle image M07-00468
MOC wide-angle image M07-00468
View full-size image, processed, in sinusoidal projection using 246.64°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 246.64°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M07-00468

Acquisition parameters
     Image ID (picno): M07-00468
     Image start time: 1999-09-02T22:11:01.56 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.04
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-PRED-X-5
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    246.64°W
Latitude  of image center:      8.17°S
       Scaled pixel width:    239.73   meters
      Scaled image  width:    116.09   km
      Scaled image height:    119.08   km
     Solar longitude (Ls):    199.15°
    Local True Solar Time:     14.71   decimal hours
           Emission angle:      3.47°
          Incidence angle:     40.44°
              Phase angle:     36.97°
            North azimuth:     93.15°
              Sun azimuth:      0.34°
      Spacecraft altitude:    379.68   km
           Slant distance:    380.31   km

Policy regarding use of processed images

Release date: 16 October 2000
