MOC wide-angle image M07-00189

context image for 188


MOC wide-angle image M07-00189
MOC wide-angle image M07-00189
View full-size image, processed, in sinusoidal projection using 262.25°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 262.25°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M07-00189

Acquisition parameters
     Image ID (picno): M07-00189
     Image start time: 1999-09-01T22:37:05.32 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.05
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    262.25°W
Latitude  of image center:     14.75°S
       Scaled pixel width:    237.72   meters
      Scaled image  width:    115.14   km
      Scaled image height:    119.16   km
     Solar longitude (Ls):    198.56°
    Local True Solar Time:     14.74   decimal hours
           Emission angle:      3.44°
          Incidence angle:     40.99°
              Phase angle:     37.56°
            North azimuth:     93.28°
              Sun azimuth:      8.40°
      Spacecraft altitude:    376.73   km
           Slant distance:    377.34   km

Policy regarding use of processed images

Release date: 16 October 2000
