MOC wide-angle image E10-01206

context image for 1205


MOC wide-angle image E10-01206
MOC wide-angle image E10-01206
View full-size image, processed but NOT map-projected
(lossy JPEG, medium quality, rapid download)
View full-size image, processed but NOT map-projected
(lossless GIF, best quality, slow download)
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image E10-01206

Acquisition parameters
     Image ID (picno): E10-01206
     Image start time: 2001-11-09T06:35:02.83 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.01
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:     13 (decimal)
Derived values
Longitude of image center:    238.73°W
 Latitude of image center:     53.67°S
       Scaled pixel width:    244.52   meters
      Scaled image  width:    118.90   km
      Scaled image height:    118.25   km
     Solar longitude (Ls):    268.60°
    Local True Solar Time:     14.15   decimal hours
           Emission angle:     18.29°
          Incidence angle:     37.29°
              Phase angle:     24.80°
            North azimuth:     95.42°
              Sun azimuth:     42.32°
      Spacecraft altitude:    373.30   km
           Slant distance:    391.06   km

Policy regarding use of processed images

Release date: 7 October 2002
