MOC narrow-angle image SP2-33806

CRATER FLOOR IN EAST ARABIA


MOC narrow-angle image SP2-33806
MOC narrow-angle image SP2-33806
View full-size image, processed, in sinusoidal projection using 311.55°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 311.55°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Hint: configure your browser to recognize files with extensions .IMG and .IMQ as MIME type application/octet-stream and to save them to disk.

Ancillary data for MOC narrow-angle image SP2-33806

Acquisition parameters
     Image ID (picno): SP2-33806
     Image start time: 1998-06-01T15:15:10.64 SCET
         Image  width:   1024      pixels
         Image height:   3584      pixels
Line integration time:      2.2100 millisec
   Pixel aspect ratio:      1.06
   Crosstrack summing:      2
    Downtrack summing:      2
     Compression type: PREDICTIVE-221
            Gain mode:     8A (hexadecimal)
          Offset mode:     32 (decimal)
Derived values
Longitude of image center:    311.55°W
Latitude  of image center:      9.70°N
       Scaled pixel width:     11.82   meters
      Scaled image  width:     12.10   km
      Scaled image height:     44.64   km
     Solar longitude (Ls):    337.67°
    Local True Solar Time:      8.25   decimal hours
           Emission angle:      8.14°
          Incidence angle:     61.88°
              Phase angle:     63.95°
            North azimuth:    266.24°
              Sun azimuth:    160.14°
      Spacecraft altitude:   1561.79   km
           Slant distance:   1572.58   km

Policy regarding use of processed images

Release date: 6 June 2000
