MOC wide-angle image M03-07615

context image for 7614


MOC wide-angle image M03-07615
MOC wide-angle image M03-07615
View full-size image, processed, in sinusoidal projection using 355.48°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 355.48°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format
Hint: configure your browser to recognize files with extensions .IMG and .IMQ as MIME type application/octet-stream and to save them to disk.

Ancillary data for MOC wide-angle image M03-07615

Acquisition parameters
     Image ID (picno): M03-07615
     Image start time: 1999-08-09T13:49:25.68 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.04
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    355.48°W
Latitude  of image center:     12.57°S
       Scaled pixel width:    238.59   meters
      Scaled image  width:    115.55   km
      Scaled image height:    119.10   km
     Solar longitude (Ls):    184.95°
    Local True Solar Time:     14.75   decimal hours
           Emission angle:      3.49°
          Incidence angle:     42.25°
              Phase angle:     38.82°
            North azimuth:     93.16°
              Sun azimuth:     14.08°
      Spacecraft altitude:    378.00   km
           Slant distance:    378.63   km

Policy regarding use of processed images

Release date: 22 May 2000
