MOC wide-angle image M03-07307

context image for 7306


MOC wide-angle image M03-07307
MOC wide-angle image M03-07307
View full-size image, processed, in sinusoidal projection using 358.01°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 358.01°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format
Hint: configure your browser to recognize files with extensions .IMG and .IMQ as MIME type application/octet-stream and to save them to disk.

Ancillary data for MOC wide-angle image M03-07307

Acquisition parameters
     Image ID (picno): M03-07307
     Image start time: 1999-08-07T12:44:00.70 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.05
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    358.01°W
Latitude  of image center:     26.51°S
       Scaled pixel width:    235.53   meters
      Scaled image  width:    114.18   km
      Scaled image height:    119.06   km
     Solar longitude (Ls):    183.78°
    Local True Solar Time:     14.80   decimal hours
           Emission angle:      3.45°
          Incidence angle:     47.49°
              Phase angle:     44.35°
            North azimuth:     93.51°
              Sun azimuth:     28.00°
      Spacecraft altitude:    373.91   km
           Slant distance:    374.52   km

Policy regarding use of processed images

Release date: 22 May 2000
