MOC wide-angle image M03-06283

context image for 6282


MOC wide-angle image M03-06283
MOC wide-angle image M03-06283
View full-size image, processed, in sinusoidal projection using 329.09°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 329.09°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format
Hint: configure your browser to recognize files with extensions .IMG and .IMQ as MIME type application/octet-stream and to save them to disk.

Ancillary data for MOC wide-angle image M03-06283

Acquisition parameters
     Image ID (picno): M03-06283
     Image start time: 1999-08-02T07:22:13.87 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.03
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-PRED-X-5
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    329.09°W
Latitude  of image center:      4.70°S
       Scaled pixel width:    240.77   meters
      Scaled image  width:    116.58   km
      Scaled image height:    118.97   km
     Solar longitude (Ls):    180.81°
    Local True Solar Time:     14.71   decimal hours
           Emission angle:      3.53°
          Incidence angle:     41.07°
              Phase angle:     37.55°
            North azimuth:     93.13°
              Sun azimuth:      8.01°
      Spacecraft altitude:    381.22   km
           Slant distance:    381.87   km

Policy regarding use of processed images

Release date: 22 May 2000
