MOC wide-angle image M03-05485

context image for 5484


MOC wide-angle image M03-05485
MOC wide-angle image M03-05485
View full-size image, processed, in sinusoidal projection using 323.99°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 323.99°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format
Hint: configure your browser to recognize files with extensions .IMG and .IMQ as MIME type application/octet-stream and to save them to disk.

Ancillary data for MOC wide-angle image M03-05485

Acquisition parameters
     Image ID (picno): M03-05485
     Image start time: 1999-07-28T03:46:29.18 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.05
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-PRED-X-5
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    323.99°W
Latitude  of image center:     18.85°S
       Scaled pixel width:    236.82   meters
      Scaled image  width:    114.74   km
      Scaled image height:    119.18   km
     Solar longitude (Ls):    177.92°
    Local True Solar Time:     14.76   decimal hours
           Emission angle:      3.47°
          Incidence angle:     45.34°
              Phase angle:     42.12°
            North azimuth:     93.39°
              Sun azimuth:     24.50°
      Spacecraft altitude:    375.48   km
           Slant distance:    376.10   km

Policy regarding use of processed images

Release date: 22 May 2000
