MOC wide-angle image M03-05094

context image for 5093


MOC wide-angle image M03-05094
MOC wide-angle image M03-05094
View full-size image, processed, in sinusoidal projection using 342.31°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 342.31°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format
Hint: configure your browser to recognize files with extensions .IMG and .IMQ as MIME type application/octet-stream and to save them to disk.

Ancillary data for MOC wide-angle image M03-05094

Acquisition parameters
     Image ID (picno): M03-05094
     Image start time: 1999-07-27T04:19:12.44 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.03
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-PRED-X-5
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    342.31°W
Latitude  of image center:      5.30°S
       Scaled pixel width:    240.85   meters
      Scaled image  width:    116.62   km
      Scaled image height:    118.98   km
     Solar longitude (Ls):    177.37°
    Local True Solar Time:     14.71   decimal hours
           Emission angle:      3.52°
          Incidence angle:     41.28°
              Phase angle:     37.80°
            North azimuth:     93.11°
              Sun azimuth:     10.88°
      Spacecraft altitude:    381.36   km
           Slant distance:    382.01   km

Policy regarding use of processed images

Release date: 22 May 2000
