MOC wide-angle image M03-03556

context image for 3555


MOC wide-angle image M03-03556
MOC wide-angle image M03-03556
View full-size image, processed, in sinusoidal projection using 330.80°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 330.80°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format
Hint: configure your browser to recognize files with extensions .IMG and .IMQ as MIME type application/octet-stream and to save them to disk.

Ancillary data for MOC wide-angle image M03-03556

Acquisition parameters
     Image ID (picno): M03-03556
     Image start time: 1999-07-18T22:16:10.77 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.04
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    330.80°W
Latitude  of image center:      9.72°S
       Scaled pixel width:    239.66   meters
      Scaled image  width:    116.06   km
      Scaled image height:    119.04   km
     Solar longitude (Ls):    172.79°
    Local True Solar Time:     14.72   decimal hours
           Emission angle:      3.50°
          Incidence angle:     42.70°
              Phase angle:     39.34°
            North azimuth:     93.19°
              Sun azimuth:     18.58°
      Spacecraft altitude:    379.60   km
           Slant distance:    380.23   km

Policy regarding use of processed images

Release date: 22 May 2000
