MOC wide-angle image M03-03554

context image for 3553


MOC wide-angle image M03-03554
MOC wide-angle image M03-03554
View full-size image, processed, in sinusoidal projection using 330.11°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 330.11°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format
Hint: configure your browser to recognize files with extensions .IMG and .IMQ as MIME type application/octet-stream and to save them to disk.

Ancillary data for MOC wide-angle image M03-03554

Acquisition parameters
     Image ID (picno): M03-03554
     Image start time: 1999-07-18T22:14:30.14 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.04
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    330.11°W
Latitude  of image center:     14.92°S
       Scaled pixel width:    238.24   meters
      Scaled image  width:    115.40   km
      Scaled image height:    119.08   km
     Solar longitude (Ls):    172.79°
    Local True Solar Time:     14.73   decimal hours
           Emission angle:      3.48°
          Incidence angle:     44.56°
              Phase angle:     41.32°
            North azimuth:     93.29°
              Sun azimuth:     23.73°
      Spacecraft altitude:    377.53   km
           Slant distance:    378.16   km

Policy regarding use of processed images

Release date: 22 May 2000
