MOC wide-angle image M03-03094

context image for 3093


MOC wide-angle image M03-03094
MOC wide-angle image M03-03094
View full-size image, processed, in sinusoidal projection using 336.11°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 336.11°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format
Hint: configure your browser to recognize files with extensions .IMG and .IMQ as MIME type application/octet-stream and to save them to disk.

Ancillary data for MOC wide-angle image M03-03094

Acquisition parameters
     Image ID (picno): M03-03094
     Image start time: 1999-07-16T21:17:24.66 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.03
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    336.11°W
Latitude  of image center:      2.80°S
       Scaled pixel width:    241.91   meters
      Scaled image  width:    117.13   km
      Scaled image height:    118.88   km
     Solar longitude (Ls):    171.66°
    Local True Solar Time:     14.69   decimal hours
           Emission angle:      3.51°
          Incidence angle:     40.97°
              Phase angle:     37.51°
            North azimuth:     93.09°
              Sun azimuth:     11.74°
      Spacecraft altitude:    383.02   km
           Slant distance:    383.66   km

Policy regarding use of processed images

Release date: 22 May 2000
