MOC wide-angle image M03-02683

context image for 2682


MOC wide-angle image M03-02683
MOC wide-angle image M03-02683
View full-size image, processed, in sinusoidal projection using 340.18°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 340.18°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format
Hint: configure your browser to recognize files with extensions .IMG and .IMQ as MIME type application/octet-stream and to save them to disk.

Ancillary data for MOC wide-angle image M03-02683

Acquisition parameters
     Image ID (picno): M03-02683
     Image start time: 1999-07-14T20:15:32.43 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.03
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    340.18°W
Latitude  of image center:      5.51°S
       Scaled pixel width:    241.16   meters
      Scaled image  width:    116.77   km
      Scaled image height:    118.93   km
     Solar longitude (Ls):    170.54°
    Local True Solar Time:     14.70   decimal hours
           Emission angle:      3.50°
          Incidence angle:     41.64°
              Phase angle:     38.22°
            North azimuth:     93.12°
              Sun azimuth:     15.49°
      Spacecraft altitude:    381.86   km
           Slant distance:    382.51   km

Policy regarding use of processed images

Release date: 22 May 2000
