MOC wide-angle image M03-01143

context image for 1142


MOC wide-angle image M03-01143
MOC wide-angle image M03-01143
View full-size image, processed, in sinusoidal projection using 357.90°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 357.90°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format
Hint: configure your browser to recognize files with extensions .IMG and .IMQ as MIME type application/octet-stream and to save them to disk.

Ancillary data for MOC wide-angle image M03-01143

Acquisition parameters
     Image ID (picno): M03-01143
     Image start time: 1999-07-06T16:11:34.89 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.03
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    357.90°W
Latitude  of image center:      4.92°S
       Scaled pixel width:    241.48   meters
      Scaled image  width:    116.93   km
      Scaled image height:    118.91   km
     Solar longitude (Ls):    166.10°
    Local True Solar Time:     14.68   decimal hours
           Emission angle:      3.47°
          Incidence angle:     41.70°
              Phase angle:     38.34°
            North azimuth:     93.06°
              Sun azimuth:     17.58°
      Spacecraft altitude:    382.40   km
           Slant distance:    383.03   km

Policy regarding use of processed images

Release date: 22 May 2000
